Batteries, Vol. 11, Pages 257: Coupling Performance of Cored and Coreless Circular Coils for WPTS: Experimental Validation Under Misalignment Scenarios

Batteries doi: 10.3390/batteries11070257

Authors:
Ahmed M. Ibrahim
Osama A. Mohammed

Wireless power transfer systems (WPTSs) are critical for efficient and reliable electric vehicle (EV) charging, but challenges such as misalignment and coupling variations limit their performance. This paper addresses a proposed design approach for WPTSs by optimizing the following two widely used coil types: ring and spiral circular coils. An analytical estimation of inductive characteristics is conducted to establish a foundation for system optimization. The study framework focuses on coil geometrical parameters and relative placements, accounting for horizontal, vertical, and angular misalignments to ensure a consistent performance under varying coupling conditions. COMSOL simulations accurately determine inductive parameters, validating the theoretical analysis for a 200 W charging coil prototype. Experimental investigations of coupling coefficients for coreless and cored charging pads highlight the superior performance of the Square I-Core-based spiral winding configuration in enhancing the coupling coefficient while ensuring that it remains below the critical value required for stable system operation. The agreement between the analytical results, simulation data, and experimental findings underscores the reliability of the proposed design approach.

Source link

Ahmed M. Ibrahim www.mdpi.com
