Processes, Vol. 14, Pages 699: Pollution Source Identification and Parameter Sensitivity Analysis in Urban Drainage Networks Using a Coupled SWMM–Bayesian Framework

Processes doi: 10.3390/pr14040699

Authors:
Ronghuan Wang
Xuekai Chen
Xiaobo Liu
Guoxin Lan
Fei Dong
Jiangnan Yang

Addressing the challenge of tracing hidden and transient cross-connections in urban drainage networks, this study develops a SWMM–Bayesian coupled model based on the Py SWMM interface using the Daming Lake area in Jinan as a case study. By employing a Markov Chain Monte Carlo (MCMC) algorithm to drive the interaction between dynamic simulation and statistical inference, the model achieves multidimensional joint posterior estimation of pollution source location (Jx), discharge intensity (M), and discharge timing (T). The results indicate: (1) Model accuracy: The coupled model demonstrates strong source tracing capability, with mean absolute errors below 0.6% in single-parameter inversion. Under multi-parameter joint inversion, the true values of all parameters consistently fall within the 95% confidence intervals. (2) Parameter sensitivity: The influence of MCMC step size on the uncertainty of pollution tracing results is systematically clarified. Discrete source location estimates (Jx) exhibit high robustness to step size variation due to spatial heterogeneity in hydraulic responses, whereas continuous physical parameters (M and T) show strong dependence on the selected step size scale. (3) Practical application: The impact of spatial monitoring network configuration on pollution tracing performance is examined. By deploying a complementary monitoring system integrating trunk and branch pipelines, the inversion accuracy for mass (M) and time (T) parameters is significantly improved by 84.2% and 88.5%, respectively. Overall, the proposed pollution source tracing method for urban drainage networks effectively overcomes the multi-solution challenge in complex network inversion, providing critical technical support for refined urban water environment management.
